PCAP Touch Monitor Description
Our PCAP touch monitors is built-to-last, using industrial grade LCD panels with high resolution, full viewing angle, square aspect ratio and long-lasting LED back light ≥50,000 hours, which ensure it to works even in harsh environment. The device offers flexible mounting options including panel mounted, VESA mounted and brackets mount. With privacy film and 3.9mm thickness glass, it is peep-proof and anti-vandal.
PCAP Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0150UA-CA6PHA(P/N:KOT-150P-015-01) | |
| Series | OT | |
| Display Type | 4:3 Ratio 15" TFT-LCD | |
| Active Area | 304.128×228.096(mm) | |
| Monitor Dimensions (W*H*D) | 369.7*292.5*48.1(mm) | |
| Suggested Resolution | 1024*768 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 350cd/m2(Typ.)/315cd/m2(Min.) |
| With Touch Monitor and peep-proof protection film | 178.5cd/m2(Typ.)/161cd/m2(Min.) | |
| Response Time (Typ.) | 30ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89°(Typ.)/85°/85°(Min.) |
| Vertical(up/down) | 89°/89°(Typ.)/85°/85°(Min.) | |
| Contrast Ratio (Typ.) | 1000:1(Typ.)/700:1(Min.) | |
| Video Input | VGA/DVI | |
| Frequency (H/V) | 37.9～80KHz / 60～75Hz | |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240V AC, 50-60 Hz The DC inner diameter of power adapter:2.1mm | |
| Environment | Operating Temp. | -10～50°C |
| Operating RH | 10%～90% | |
| Storage Temp. | -20～70°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥50,000 Hours | |
| LED Back Light Life (Typ.) | ≥50,000 Hours | |
| Weight(N.W/G.W) | 3.0Kg(1pcs)/7.2Kg(2pcs in one package) | |
| Package dimensions | 445*200*395(mm)(2pcs in one package) | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤15W | |
| Mount Interface | Mount bracket, horizontal or vertical mount | |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, CE, CB, RoHS | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 15" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤10ms |
| Resolution ratio | 16384*9600 |
| Hardness | 7H |
| Light Transmittance | ≥85% |
| Anti-vandal test | 500g steel ball drop from 1.3m high test |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 304*228(mm) |
| Thickness | 3.9±0.2(mm) |
| Touch Test | 50,000,000 times |
| Input Voltage | 5V |
| Peep-proof protection film | |
| Type | peep-proof protection film |
| The angle range of Anti-peep | Horizontal(left/right): 35°±5° |
| Thickness | 0.58±0.05(mm) |
| Light Transmittance | ≥60%±5% |
PCAP Touch Monitor Mechanical Dimensions
Applications
Our PCAP touch monitors are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Do you have stock for PCAP touch monitors?
Yes, we have a large quantity of stock for our regular model products.
2.Do you give any discount for PCAP touch monitors?
We will do utmost to support you with the competitive price, also good service will be offered.
3. What is your warranty period for PCAP touch monitors?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
5. What’s your MOQ for PCAP touch monitors?
Our minimum order quantity is 1pc only.
